Cameras with Sony IMX547 Sensor: Specs, Prices & Life Cycle
Gaspar van Elmbt
This article contains the main specifications of Sony IMX547 image sensor. Additionally, the article explores how the sensor can be integrated into different camera interfaces such as GigE and USB3, depending on the desired features. Finally, it provides a brief overview of selecting compatible industrial lenses to maximize the IMX547's performance.
Download here the machine vision camera manual that includes the specifications of our cameras with Sony IMX547, the spectral response graphs and mechanical drawings.
Table of contents
Sony IMX547 image sensor specifications
The Sony IMX547 is a high-performance CMOS image sensor designed for industrial and machine vision applications. It features a resolution of 5 megapixels (2448x2048), a pixel size of 2.47μm, and a global shutter type. The IMX547 can achieve a maximum frame rate of 58fps at full resolution for the GigE interface. The Sony IMX547 image sensor belongs to the Sony Pregius 4th Generation. On the same generation, you can find models with resolutions 8 MP (IMX546), 12.21 MP (IMX545), 16.1 MP (IMX542), 20.2 MP (IMX541), and 24.4 MP (IMX540).
2nd generation Pregius sensors vs 4th generation Pregius S sensors
Sony's 2nd and 4th generation IMX sensors show clear technological progress. IMX547 belongs to the 2nd gen sensors. They have 3.45 μm pixels, offering resolutions up to 12 MP. They perform well in low light and can achieve high frame rates, especially in their high speed versions. The 4th gen Pregius S sensors use smaller 2.74 μm pixels, allowing for higher resolutions up to 24.5 MP. Despite smaller pixels, they maintain good sensitivity thanks to improved design. These newer sensors also introduce advanced features like dual ADC and exposure time monitoring. They use stacked CMOS technology, which helps maintain performance despite the smaller pixel size. In essence, while 2nd gen sensors are still capable, the 4th gen sensors
offer higher resolution, more features, and better efficiency, making them more suitable for advanced imaging applications.
Sony Pregius 2nd generation is still one of the most light sensitive solutions for standard machine vision cameras. A light sensitivity comparison between 2nd and 4th generation can be found in this article.
Sony IMX547 sensor for GigE vision camera
The IMX547 sensor is well-suited for GigE cameras, which provide a robust and reliable interface for industrial applications. GigE cameras offer long cable lengths, up to 100 meters, making them ideal for distributed systems and applications where the camera needs to be located away from the host computer. Our GigE cameras models with IMX547 are MER3-506-58G3M-P and MER3 506-58G3C-P. For our GigE cameras, you can download the camera manual, free SDK and 3D files in our Download page. This 5 MP camera offers 58 frames per second.
Industrial lens for Sony IMX547 camera
When selecting an industrial lens for the IMX547 sensor, it is important to consider factors such as the sensor size, resolution, and the specific application requirements. High-quality lenses designed for machine vision applications can help maximize the performance of the IMX547 sensor and ensure optimal image quality. With a pixel size of 3,45μm and resolving power of 160 lp/mm our industrial C-mount lenses from 1/1.8” 5MP series are ideal to combine with IMX547.
Do you need help choosing the right lens? You can use our Lens calculator tool. Additionally, feel free to fill out the short form below, and our experts will be happy to recommend the most suitable camera-lens setup for your specific needs!
Spectral response of IMX547 monochrome and color sensors
Product life cycle of Sony IMX547
The IMX547 sensor is a mature sensor with a proven track record in the machine vision market. This means it has been around for a significant amount of time and has a well-established reputation for performance and reliability. Because of this maturity, you can be confident that the IMX547 sensor will deliver consistent image quality and operate reliably for years to come.
Here at VA Imaging, we understand the importance of choosing the right sensor for your machine vision application. That's why we are proud to offer a wide range of cameras that utilize the IMX547 sensor. In fact, we produce tens of thousands of cameras per year that use sensors up to 6 megapixels, with the IMX547 being a popular choice. This high production volume speaks to the versatility and effectiveness of this sensor in a wide variety of machine vision tasks.
In conclusion, the IMX547 sensor's maturity, proven track record, and high production volume make it a reliable and cost-effective option for many machine vision applications. If you are considering a camera with the IMX547 sensor, you can be assured that you are
making a solid investment.
