Powersupply / light controller Digital Powersupply-lighting

Powersupply / light controller Digital

  • 4 Channels
  • 24V/200W
  • Din rail
Powersupply / light controller Digital, 4 Channels, 24V/200W, Din rail Powersupply / light controller Digital
€456,00
Delivery time: Standard 3-6, Express 0-3 weeks
Industrial Quality
Machine Vision
Description

Industrial Machine Illumination Power Supply Digital Series 24V

Four channel powersupply / machine vision light controller, to independently control the light intensity of 4 different machine vision lights.

Powersupply / light controller Digital, 4 Channels, 24V/200W, Din rail

The powersupply has a 230V input and 4x 24V output channels. Max 3A per channel and it can deliver up to 200 Watt in total. Each channel can be triggered separately. This powersupply is ideal for adjusting the power of your industrial machine vision light. This machine vision lighting controller / powersupply includes a mount for Din Rail.

More info
Part number VA-PS5-D4-200W-24V

Characteristics

  • 0 ~ 255 stepless light intensity control
  • External trigger input for strobe lighting
  • Mains powered
  • Built in over-current protection
  • DIN-rail or bottom screw mounting options
  • Configurable over RS232 or Ethernet



How To Trigger The Lights

The light can be triggered using the Triggering ports on the power supply. The wiring diagram for using our industrial cameras is shown above. Triggering the LED light instead of leaving it continuously on will increase the life span of the LED light. Each light channel can be triggered separately. The intensity of the light can be controlled by the rotary knob.


Download Power Supply Datasheet

In our bar light datasheet you find the mechanical dimensions, wavelengths, operating temperature, compatible powersupplies and so on. Login using your email address and get instantly access to our bar light datasheets.

€456,00
